OSG 1 BA S-POT
£0.00 Net price excl. VAT
0 in stock (UK Warehouse)
Other warehouses :
96 in stock (Europe Warehouse)
| EDP | Family |
|---|---|
| 48272911 | S-POT |
Specifications
THREAD TYPE
BA
THREAD DIAMETER (TD)
1
THREAD PITCH/THREAD PER INCH (TP_TPI)
0.9000
CONNECTION DIAMETER (DCON)
5.6000
DRIVE SIZE (DRVS)
4.5000
HOLE TYPE APPLICATION
Through Hole
FUNCTIONAL LENGTH (LF)
62.00
USABLE LENGTH (LU)
26
FLUTE COUNT (NOF)
3.00
PREMACHINED HOLE DIAMETER (PHD)
4.4
TAP TYPE
Cutting tap
THREAD CHAMFER LENGTH (THCHL)
4.00
THREAD CHAMFER TYPE FORM (THCHT)
B
THREAD LENGTH (THLGTH)
17.00
THREAD DIAMETER (TD_MM)
0.2087
THREAD DIAMETER (TD_MM)
5.3000
THREAD PITCH (TP)
0.9000
Material
Steel
Stainless steel
Cast iron
Download format drawings
