OSG M 14 x2 S-POT D1835 Weldon DIN 376
£0.00 Net price excl. VAT
0 in stock (UK Warehouse)
Other warehouses :
63 in stock (Europe Warehouse)
| EDP | Family |
|---|---|
| 48279191 | S-POT-HB Weldon |
Key Features
- HSSE spiral-point cutting tap for through holes
- Steam oxide treatment
- General purpose tapping in steels and stainless steels
- With Weldon shank
Specifications
THREAD TYPE
M
THREAD DIAMETER (TD)
14
THREAD PITCH/THREAD PER INCH (TP_TPI)
2.00
CONNECTION DIAMETER (DCON)
14.00
DIN
371/1835
DRIVE SIZE (DRVS)
11.00
HOLE TYPE APPLICATION
Through Hole
FUNCTIONAL LENGTH (LF)
110.00
USABLE LENGTH (LU)
49
FLUTE COUNT (NOF)
3.00
PREMACHINED HOLE DIAMETER (PHD)
12
TAP TYPE
Cutting tap
THREAD CHAMFER LENGTH (THCHL)
4.00
THREAD CHAMFER TYPE FORM (THCHT)
B
THREAD LENGTH (THLGTH)
30.00
THREAD TOLERANCE
ISO2-6H
PHD_MAX
12.2100
PHD_MIN
11.8350
THREAD DIAMETER (TD_MM)
0.5512
THREAD DIAMETER (TD_MM)
14.00
THREAD PITCH (TP)
2.00
SHANK TYPE
HB
Material
Steel
Stainless steel
Cast iron
